Blue Sea 2356100 - Water Resistant 100A Busbar w/Cover [2356100]

$40.99 USD$56.99 USD
Authorized Blue Sea Systems Dealer
Kayak shipping available, rates calculated at checkout.
Questions? Call our experts at 404-422-9569.
Logo for GOVX ID, a service used to verify military, first responder, nurse or teachers to qualify them for discounts

Discount available for Military, First Responders, Medical Workers and Teachers

Quantity

2356100 - Water Resistant 100A Busbar with Cover

Water-resistant bussing for harsh environments.  Built with wing screws for toolless access.

Features:

  • Accepts a wide range of wire sizes
    • Includes 3 wire plugs to maintain a water-resistant rating if less than 4 wires are used
    • Nests with other water-resistant 100A common busbars and ST-Blade water resistant fuse block for space-saving wiring
    • Ideal for positive distribution and for the collection of negative or AC ground circuits
    • Meets ABYC/USCG insulation requirements
    • Tin-plated copper busses and fuse clips
    • Includes four (4) write-on circuit labels
    • Small format standard and custom labels are available
    • Wing-screws designed for tool-free installation of cover to meet ABYC compliance

Technical Specifications:

  • Cover - yes
  • Maximum Voltage - 300V AC - 48V DC
  • Terminal Stud - 1 x #10-32
  • Continuous Rating - 100A AC or DC
  • Bus Material - Tin-plated Copper
  • Mounting Holes - Accepts 1/4" (6mm) screws
  • Terminal Screws - 4 x # 8-32
  • Wire Size - Input - (1) 8 AWG to 4 AWG
  • Wire Size - Load - (4) 16 AWG to 10 AWG

In the Box:

  • 2356100 Busbar
  • Instruction Manual

*Sold as an Individual


Quick Guide (pdf)
